Ford Fusion: Front Suspension / Wheel Studs. Removal and Installation

Ford Fusion 2013–2020 Service Manual / Chassis / Suspension / Front Suspension / Wheel Studs. Removal and Installation

Special Tool(s) / General Equipment

Hydraulic Press

Removal

  1. Remove the front wheel bearing and wheel hub.
    Refer to: Front Wheel Bearing and Wheel Hub (204-01 Front Suspension, Removal and Installation).
  1. Press the wheel stud from the wheel bearing and wheel hub.
    Use the General Equipment: Hydraulic Press
Ford Fusion. Wheel Studs. Removal and Installation
  1. Inspect the wheel bearing and wheel hub for damage. Replace as necessary.
Ford Fusion. Wheel Studs. Removal and Installation

Installation

  1. Press the wheel stud into the wheel bearing and wheel hub.
    Use the General Equipment: Hydraulic Press
Ford Fusion. Wheel Studs. Removal and Installation
  1. Install the wheel bearing and wheel hub.
    Refer to: Front Wheel Bearing and Wheel Hub (204-01 Front Suspension, Removal and Installation).
